Challenger 70C
| | 1995 - 1996 |
| Agricultural Crawler tractor |
|
Series map:
65C
70C
75C
285.0hp
285.0hp
325.0hp
| Production |
| Manufacturer | Challenger (a part of Caterpillar)
|
| Agricultural Crawler tractor |
| Built in Peoria, Illinois, USA |
| Challenger 70C Power |
| Engine | 285 hp
212.5 kW
|
| Drawbar (claimed) | 225 hp
167.8 kW
|
| PTO (claimed) | 250 hp
186.4 kW
|
| Mechanical |
| Drive | crawler
|
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard. |
| Capacity |
| Fuel | 209 gal
791.1 L
|
| Hydraulic system | 29 gal
109.8 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 29 gal
109.8 L
|
| Pressure | 2550 psi
175.8 bar
|
| Valves | 4
|
| Pump flow | 27 gpm
102.2 lpm
|
| | 35 gpmOptOptional
132.5 lpm
|
| Steering flow | 61.4 gpm
232.4 lpm
|
| Steering press. | 6090 psi
419.9 bar
|
| Power Take-off (PTO) |
| Rear PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 115
|
| Batteries | 2
|
| Battery CCA | 750
|
| Battery volts | 12
|
| References |
 |
| Challenger Agricultural Tractor published in 1993, by Caterpillar |
