Massey Ferguson 1120
|
|
| Production | |
| Distributor | Massey Ferguson |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Built in Japan | |
| Original price was $10,000 in 1996 | |
| Massey Ferguson 1120 Engine | |
| Iseki 0.9L 3-cyl diesel | |
| Fuel tank | 3.2 gal 12.1 L |
 Engine details ... | |
| Massey Ferguson 1120 Transmissions | |
| 6-speed gear | |
| hydrostatic | |
 Transmission details ... |
| Massey Ferguson 1120 Power | |
| Engine (gross) | 16.6 hp 12.4 kW |
| Engine (net) | 15.5 hp 11.6 kW |
| Gear PTO (claimed) | 13.5 hp 10.1 kW |
| Hydro PTO (claimed) | 13 hp 9.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Manual steering | |
| Mechanical drum brakes | |
| Two-post fixed ROPS. |
| Hydraulics | |
| Type | open center |
| Pressure | 1950 psi 134.5 bar |
| Pump flow | 3.5 gpm 13.2 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 830 lbs 376 kg |
| Power Take-off (PTO) | |
| Gear Rear PTO | transmission |
| Hydro Rear PTO | live |
| Clutch | dry disc |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Gear Wheelbase | 50.4 inches 128 cm |
| Hydro Wheelbase | 54.1 inches 137 cm |
| Weight | 1272 to 1360 pounds |
| Front tire | 5.00-12 |
| Rear tire | 8-18 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 35 |
| Battery CCA | 325 |
| Battery volts | 12 |
| References | |
 | |
| 1120-4 compact tractor published in 1994, by CaseIH | |
| 1120-4WD compact tractor published in 1994, by CaseIH |
