Oliver 1870
| | 1973 - 1974 |
| Row-Crop tractor |
|
Series map:
1870
2270
107.8hp*
163.3hp*
*Estimated engine power for comparison only.
Note: the Oliver model 1870 is the same as the Minneapolis-Moline G955. The following data is from the G955 listing. |
| Production |
| Manufacturer | Oliver (a part of White)
|
| Row-Crop tractor |
| Original price was $13,700 in 1974 |
| Oliver 1870 Power |
| Drawbar (claimed) | 80 hp
59.7 kW
|
| Diesel PTO (claimed) | 97 hp
72.3 kW
|
| LP-gas PTO (claimed) | 92 hp
68.6 kW
|
| Drawbar (tested) | 80.19 hp
59.8 kW
|
| PTO (tested) | 98.8 hp
73.7 kW
|
 Performance test details ... |
| Mechanical |
| Two-wheel drive |
| Power steering |
| Disc brakes |
| Open operator station. Cab optional. |
| Photos |
| No photos of the Oliver 1870 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 40 gal (diesel)
151.4 L
|
| | 39 gal (LP-Gas)
147.6 L
|
| Hydraulic system | 6.8 gal
25.7 L
|
| Hydraulics |
| Type | closed center
|
| Capacity | 6.8 gal
25.7 L
|
| Pressure | 2200 psi
151.7 bar
|
| Pump flow | 20 gpm
75.7 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| 1870 Serial Numbers |
| Location: | Serial number plate below the instrument panel, behind the clutch pedal.
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| Technical Service Manual Electrical Systems (432613) published in 1973 |
| Technical Service Manual 55 Series Tractor Hydraulics (432616) published in 1973 |
