New Holland 8260

New Holland 8260 tractor photo
1996 - 1999
60 Gemini Series
Row-Crop tractor
Manufacturer:New Holland
Type:Row-Crop tractor
Original price:$48,000 (1999)
Fiat M115
New Holland 8260 Power
PTO (claimed):100 hp
74.6 kW
Drawbar (tested):88 hp
65.6 kW
PTO (tested):107 hp
79.8 kW
power test details ...
New Holland 8260 Engine
New Holland 7.5L 6-cyl diesel
Engine details ...
Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Differential lock:Rear (2WD) or front and rear (4WD) with push-button operation. Manual and automatic modes.
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Cab:Two-post ROPS. Optional cab.
Transmissions:23-speed partially synchronized
 17-speed partial power shift
 18-speed partial power shift
Transmission details ...
Fuel:85 gal
321.7 L
Hydraulic system:23.7 gal
89.7 L (18-speed)
 19.2 gal
72.7 L (23-speed)
Front hubs:1.8 qts
1.7 L (each)
Front diff.:2.3 qts
2.2 L
Type:closed center load sensing
Capacity:23.7 gal
89.7 L (18-speed)
 19.2 gal
72.7 L (23-speed)
Pressure:2755 psi
190.0 bar
Valves:2 to 4
Pump flow:26 gpm
98.4 lpm
Steering flow:15.6 gpm
59.0 lpm
Steering press.:2465 psi
170.0 bar
Tractor hitch
Rear Type:II
Rear lift (at 24"/610mm):8,500 lbs
3855 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:108.3 inches
275 cm (2WD)
 107.2 inches
272 cm (4WD)
Weight:11616 to 12606 pounds
Front tire:11.00-16
Rear tire:18.4R38 (2WD)
Full dimensions and tires ...
Charging system:alternator
Charging amps:70
 100 (with cab)
Battery CCA:900
Battery volts:12
