White 4-175 Field Boss
|
|
| Production | |
| Manufacturer | White |
| Four-wheel Drive (4WD) tractor | |
| Original price was $54,000 in 1983 | |
| White 4-175 Engine | |
| Caterpillar 10.4L 8-cyl diesel | |
| Fuel tank | 94 gal 355.8 L |
| 172 gal*Total capacity with two optional 39 gallon fender tanks. 651.0 L | |
 Engine details ... | |
| White 4-175 Transmission | |
| 18-speed three-speed power shift | |
 Transmission details ... |
| White 4-175 Power | |
| Engine | 175 hp 130.5 kW |
| Drawbar (tested) | 127.15 hp 94.8 kW |
| PTO (tested) | 151.69 hp 113.1 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Articulated power steering | |
| Hydraulic dry disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the White 4-175 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center |
| Pressure | 2250 psi 155.1 bar |
| Valves | 2 pr 3 |
| Pump flow | 22 gpm 83.3 lpm |
| Tractor hitch | |
| Rear Type | III/II |
| Control | lower-link draft sensing |
| Rear lift (at 24"/610mm) | 6000 lbs 2721 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 118.4 inches 300 cm |
| Weight | 20,420 lbs 9262 kg |
| Front tire | 18.4-34 |
| Rear tire | 18.4-34 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 80 |
| Batteries | 2 |
| Battery CCA | 625 |
| Battery volts | 12 |
| References | |
 | |
| 4-175 Field Boss published by White | |
| New 4-175 Field Boss published in 1979, by White |
