Iseki T6500
|
|
| Production | |
| Manufacturer | Iseki |
| Utility tractor | |
| Built in Japan | |
| Iseki T6500 Engine | |
| Isuzu 3.6L 4-cyl diesel | |
| Fuel tank | 27.5 gal 104.1 L |
 Engine details ... | |
| Iseki T6500 Transmission | |
| 20-speed gear | |
 Transmission details ... |
| Iseki T6500 Power | |
| Engine | 64.1 hp 47.8 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS. Cab available with heater. | |
| Photos | |
| No photos of the Iseki T6500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 11.5 gpm 43.5 lpm |
| Steering flow | 8 gpm 30.3 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@1814 |
| 850@2200 | |
| Dimensions & Tires | |
| Wheelbase | 84.7 inches 215 cm |
| Weight | 5423 to 5986 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 16.9/14-30 |
 Full dimensions and tires ... | |
| T6500 Serial Numbers | |
| Location: | Serial number behind alternator. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 30 |
| Batteries | 2 |
| Battery volts | 12 |
| Battery AH | 80 |
| References | |
 | |
| Tractor T Series published in 1981, by Iseki |
