Iseki T5000


Iseki T5000 tractor photo
1980 - 1981
Utility tractor
Series map:
T5000
T6000
35.3kw
44.7kw
Production
ManufacturerIseki
Utility tractor
Built in Japan
Variants
2-45similar White model
Iseki T5000 Engine
Isuzu 2.8L 4-cyl diesel
Fuel tank15.9 gal
60.2 L
Engine details ...
Iseki T5000 Power
Engine47.3 hp
35.3 kW
PTO (claimed)43 hp
32.1 kW
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockmechanical rear
Power steering
Wet disc brakes
Four-post ROPS. Cab available with heater.
Photos
No photos of the Iseki T5000 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Steering flow8 gpm
30.3 lpm
Tractor hitch
Rear TypeII
Controlposition and draft control
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic
Rear PTO Type540 (1.375)
Engine RPM540@1814
 869@2250
Dimensions & Tires
2WD Wheelbase78.7 inches
199 cm
4WD Wheelbase80.1 inches
203 cm
Weight5214 to 5721 pounds
Front tire6.50-16
2WD Rear tire14.9/13-28
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps30
Batteries2
Battery volts12
Battery AH80
References
T5000 references literature
Technical Annual published in 1983, by Power Farming
Tractor T Series published in 1981, by Iseki
