Iseki T5000
| 1980 - 1981 |
Utility tractor |
|
Series map:
T5000
T6000
35.3kw
44.7kw
Production |
Manufacturer | Iseki
|
Utility tractor |
Built in Japan |
Variants |
2-45 | similar White model
|
Iseki T5000 Power |
Engine | 47.3 hp 35.3 kW
|
PTO (claimed) | 43 hp 32.1 kW
|
Mechanical |
Two- or four-wheel drive |
Final drives | inboard planetary
|
Differential lock | mechanical rear
|
Power steering |
Wet disc brakes |
Four-post ROPS. Cab available with heater. |
Photos |
No photos of the Iseki T5000 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type | open center
|
Steering flow | 8 gpm 30.3 lpm
|
Tractor hitch |
Rear Type | II
|
Control | position and draft control
|
Power Take-off (PTO) |
Rear PTO | independent
|
Clutch | hydraulic
|
Rear PTO Type | 540 (1.375)
|
Engine RPM | 540@1814
|
  | 869@2250
|
Electrical |
Ground | negative
|
Charging system | alternator
|
Charging amps | 30
|
Batteries | 2
|
Battery volts | 12
|
Battery AH | 80
|
References |
 |
Technical Annual published in 1983, by Power Farming |
Tractor T Series published in 1981, by Iseki |
