J.I. Case 640
|
|
| Production | |
| Manufacturer | J.I. Case |
| Utility tractor | |
| Factories | Rock Island, Illinois, USA |
| Racine, Wisconsin, USA | |
| Original price | $3,900 |
| J.I. Case 640 Engines | |
| J.I. Case 3.1L 4-cyl gasoline | |
| J.I. Case 3.1L 4-cyl LP gas | |
| Fuel tank | 22 gal 83.3 L |
 Engine details ... | |
| J.I. Case 640 Transmissions | |
| 8-speed torque converter | |
| 12-speed | |
| 8-speed | |
| 4-speed gear | |
 Transmission details ... |
| J.I. Case 640 Power | |
| Belt (claimed) | 52 hp 38.8 kW |
| Drawbar (tested) | 43.25 hp 32.3 kW |
| PTO (tested) | 50.61 hp 37.7 kW |
 Performance test details ... | |
| Mechanical | |
| Two-wheel drive | |
| Steering | power assist |
| Differential mechanical dry disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the J.I. Case 640 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | Dual-Control |
| Tractor hitch | |
| Type | Case Eagle Hitch |
| Power Take-off (PTO) | |
| Rear PTO | continuous |
| independent (Case-o-matic) | |
| Rear PTO Type | 540 (1.375) |
| 540/1000 (1.375) | |
| Dimensions & Tires | |
| Weight | 4,500 lbs 2041 kg |
| Front tire | 7.50-16 |
| Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| 640 Serial Number Location | |
 | |
| Serial number plate on the right side of the instrument panel. |
| Belt Pulley | |
| Diameter | 9.25 inches 23 cm |
| Width | 6 inches 15 cm |
| References | |
 | |
| 1960 Progress Parade of Case Farm Equipment published by J.I. Case | |
| A Complete New Line of Case Plus-Powered Tractors published in 1960, by J.I. Case |
