Big Bud 360/10


No photo available
1979 - 1980
3 Series
Four-wheel Drive (4WD) tractor
Production
Manufacturer:Big Bud
Type:Four-wheel Drive (4WD) tractor
Factory:Havre, Montana, USA
Original price:$103,000 (1978 )
Variants
360/10:gear shift
360/30:power shift
Big Bud 360/10 Power
Engine:360 hp
268.5 kW
Big Bud 360/10 Engine
Cummins 14.0L 6-cyl diesel
Fuel tank:550 gal
2081.8 L
Engine details ...
Mechanical
Chassis:4x4 articulated 4WD
Steering:articulated power
Brakes:pneumatic drum
Cab:Cruiser Cab standard.
Transmission:12-speed gear
Transmission details ...
Photos
No photos of the Big Bud 360/10 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center
Valves:4
Pump flow:36 gpm
136.3 lpm
Steering flow:35 gpm
132.5 lpm
Dimensions & Tires
Wheelbase:150 inches
381 cm
Weight:39000 lbs
17690 kg
Front tire:24.5-32
Rear tire:24.5-32
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:75
Battery volts:12
