International Harvester 6388
|
|
| Production | |
| Manufacturer: | International Harvester |
| Total built: | 272 |
| Original price: | $61,400 (1984 ) |
| International Harvester 6388 Power | |
| Engine: | 157 hp 117.1 kW |
| Drawbar (claimed): | 114 hp 85.0 kW |
| PTO (claimed): | 130 hp 96.9 kW |
| Drawbar (tested): | 111.75 hp 83.3 kW |
| PTO (tested): | 130.61 hp 97.4 kW |
| International Harvester 6388 Engine | |
| International Harvester 7.1L 6-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x4 articulated 4WD |
| Steering: | articulated hydrostatic power |
| Cab: | Cab standard with burgundy finish, heat, and A/C. Optional western finish interior. |
| Transmission: | 16-speed two-range power shift |
 Transmission details ... | |
| Capacity | |
| Fuel: | 89 gal 336.9 L |
| 139 gal 526.1 L (optional) | |
| Hydraulic system: | 23.6 gal 89.3 L |
| Hydraulics | |
| Type: | closed center |
| Capacity: | 23.6 gal 89.3 L |
| Valves: | 2 to 4 |
| Pump flow: | 18 gpm 68.1 lpm |
| Steering flow: | 12 gpm 45.4 lpm |
| Tractor hitch | |
| Rear Type: | III/II |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
| Dimensions & Tires | |
| Wheelbase: | 110 inches 279 cm |
| Weight: | 15960 lbs 7239 kg |
| Front tire: | 16.9-38 |
| Rear tire: | 16.9-38 |
 Full dimensions and tires ... | |
| 6388 Serial Numbers | |
| Location: | transmission housing, right side |
| 1981: | 8801 |
| 1982: | 8962 |
| 1983: | 9060 |
| 1984: | 9241 |
| 1985: | 9361 |
