International Harvester 1486 Tests

International Harvester 1486 tractor photo
1976 - 1981
86 Series
Row-Crop tractor
Series map:
*Estimated engine power for comparison only.
Nebraska Tractor Test 1125
1486 fuel use from test 1125
Nebraska Tractor Test 1125
Diesel TA 2WD
April 17 - 27, 1973
Link: Nebraska Tractor Test 1125 file
PTO performance
Power at rated engine speed145.77 hp
108.7 kW
Fuel use9.6 gal/hour
36.3 l/hour
Power at rated PTO speed145.85 hp
108.8 kW
Fuel use8.6 gal/hour
32.6 l/hour
Drawbar performance
Max power123.20 hp
91.9 kW
Fuel use9.5 gal/hour
36.0 l/hour
Gear 1-Hi-TA used for power test.
Max pull13,673 lbs
6202 kg
Gear 3-Lo-TA used for pull test.
