International Harvester 784
| | 1977 - 1984 |
| 84 Series | | Utility tractor |
|
Series map:
684
784
884
69.0hp
74.9hp*
81.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | International Harvester
|
| Utility tractor |
| Built in Doncaster, England |
| Original price was $22,300 in 1984 |
| The International Harvester 784 was available in three configurations: row-crop, utility, and low-profile. The front axle and rear wheel were the primary difference between the three versions of the 784. |
| International Harvester 784 Power |
| Drawbar (claimed) | 58.6 hp
43.7 kW
|
| PTO (claimed) | 67.4 hp
50.3 kW
|
| Drawbar (tested) | 56.83 hp
42.4 kW
|
| PTO (tested) | 67.48 hp
50.3 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Independent hydraulic wet disc brakes |
| ROPS standard, except on low-profile. Canopy optional. Cab optional on row-crop. |
| Capacity |
| Fuel | 20 gal
75.7 L
|
| Hydraulic system | 9 gal
34.1 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 9 gal
34.1 L
|
| Valves | 1 or 2
|
| Pump flow | 13 gpm
49.2 lpm
|
| | 15.4 gpm (optional)
58.3 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 3600 lbs
1632 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | hydraulic wet disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Dimensions & Tires |
| Utility Wheelbase | 88 inches
223 cm
|
| Row-crop Wheelbase | 84.5 inches
214 cm
|
| 4WD Wheelbase | 85.2 inches
216 cm
|
| Low-profile Wheelbase | 83.75 inches
212 cm
|
| Weight | 5850 to 7108 pounds
|
| Front tire | 7.50-16
|
| Rear tire | 16.9-30
|
 Full dimensions and tires ... |
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| References |
 |
| 1979 Buyer's Guide published by International Harvester |
| Buyer's Guide 1981 published by International Harvester |
| Buyer's Guide 1982 published by International Harvester |
| 84 Series Hi-Performers published in 1978, by International Harvester |
| International Series 84 Utility/Row-Crop Tractors published in 1978, by International Harvester |
| International Series 84 tractors published in 1982, by International Harvester |
| International Series 84 Tractors published in 1983, by International Harvester |
| Agricultural Equipment Reference Catalog published in 1980, by International Harvester |
