Ford 6700
| | 1977 - 1981 |
| Row-Crop tractor |
|
Series map:
6700
7700
75.5hp
96.7hp
| Production |
| Manufacturer | Ford
|
| Row-Crop tractor |
| Original price was $22,000 in 1981 |
| Variants |
| 6600 | utility chassis
|
| 6700 | row-crop chassis
|
| Ford 6700 Power |
| Engine (gross) | 75.5 hp
56.3 kW
|
| Engine (net) | 72.5 hp
54.1 kW
|
| PTO (claimed) | 70 hp
52.2 kW
|
| Drawbar (tested) | 56.17 hp
41.9 kW
|
| PTO (tested) | 70.56 hp
52.6 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | mechanical rear
|
| Power steering |
| Open operator station. Cab optional with available heater and air-conditioning. |
| Hydraulics |
| Type | open center
|
| Pressure | 2100 psi
144.8 bar
|
| Valves | 1 or 2
|
| Pump flow | 9.7 gpm
36.7 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | top-link draft sensing
|
| Rear lift | 4040 lbs
1832 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540
|
| | 540/1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 32
|
| | 51 *Optional, standard with cab.
|
| Battery volts | 12
|
| Battery AH | 128
|
| References |
 |
| Ford 6700 published in 1978 |
| Ford now offer tractor from 37 to 295 horsepower published in 1979* |
| *Publication contains known errors. |
