Ford 5900
| | 1985 - 1993 |
| Utility tractor |
|
| Production |
| Manufacturer: | Ford
|
| Type: | Utility tractor
|
| Original price: | $17,400 (1993 )
|
| Ford 5900 Power |
| Engine (gross): | 73 hp
54.4 kW
|
| Drawbar (claimed): | 53 hp
39.5 kW
|
| PTO (claimed): | 62 hp
46.2 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Cab: | Two-post fixed ROPS.
|
| Transmission: | 8-speed sliding gear
|
 Transmission details ... |
| Capacity |
| Fuel: | 20 gal
75.7 L
|
| Hydraulic system: | 14 gal
53.0 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 14 gal
53.0 L
|
| Valves: | 1
|
| Pump flow: | 6 gpm
22.7 lpm
|
| Steering flow: | 3.6 gpm
13.6 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift: | 3340 lbs
1515 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| Engine RPM: | 540@1900
|
| 5900 Serial Numbers |
| Location: | Transmission, upper front-right
|
| 1985: | ZX00001
|
| 1986: | ZX00486
|
| 1987: | ZX00700
|
| 1988: | ZX01046
|
| 1989: | ZX02245
|
| 1990: | ZX03006
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 32
|
| Battery volts: | 12
|
| Battery AH: | 128
|
| Page information |
| Last update: | September 5, 2019
|
| Copyright: | Copyright 2022 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Ford 5900 photos...
