| | 1975 - 1981 |
| Utility tractor |
|
Series map:
2600
3600
36.5hp
48.0hp
| Transmissions overview |
| 6-speed gear |
| 8-speed |
| 6-speed mechanical shuttle |
| Transmission |
| Type | gear
|
| Gears | 6 forward and 2 reverse
|
| Clutch | 279mm dry disc
|
| Oil capacity | 13.8 qts
13.1 L
|
| Speeds |
| With 12.4-28 rear tires. |
|
| Transmission |
| Transmission | Dual-Range
|
| Gears | 8 forward and 2 reverse
|
| Clutch | 279mm dry disc
|
| Oil capacity | 13.8 qts
13.1 L
|
| Speeds |
| With 12.4-28 rear tires. |
|
| Shift Pattern |
 |
| Transmission |
| Type | mechanical shuttle
|
| Gears | 6 forward and 4 reverse
|
