Allis Chalmers 6140
| | 1982 - 1985 |
| Utility tractor |
|
| Production |
| Manufacturer: | Allis Chalmers
|
| Type: | Utility tractor
|
| Original price: | $15,891
|
| Allis Chalmers 6140 Power |
| PTO (claimed): | 40 hp
29.8 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Final drives: | inboard planetary
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | mechanical wet disc
|
| Cab: | Open operator station. ROPS and canopy available.
|
| Transmission: | 10-speed synchromesh
|
 Transmission details ... |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 10 gpm
37.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | top-link draft sensing
|
| Rear lift: | 3190 lbs
1446 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540
|
| 6140 Serial Numbers |
| Location: | Serial number on the left side of the fuel tank.
|
| 1982: | 1001
|
| 1983: | 1726
|
| 1984: | 1851
|
| 1985: | 2711
|
how to read serial numbers...
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
