John Deere 8760 Tests
|
|
| Tractor Tests | |
| OECD 1624: diesel Powr-Sync 4WD | |
| OECD 1631: diesel Power shift 4WD |
| OCED Tractor Test 1624 | |||
| |||
| OCED Tractor Test 1624 | |
| Diesel Powr-Sync 4WD May 1989 - 1989, Link: OCED Tractor Test 1624 file | |
| PTO performance | |
| Power at rated engine speed | 256.94 hp 191.6 kW |
| Fuel use | 16.4 gal/hour 62.1 l/hour |
| Power at rated PTO speed | 277.41 hp 206.9 kW |
| Fuel use | 16.1 gal/hour 60.9 l/hour |
| Drawbar performance | |
| Max power | 237.21 hp 176.9 kW |
| Fuel use | 15.8 gal/hour 59.8 l/hour |
| Max pull | 32880 lbs 14914 kg |
| OCED Tractor Test 1631 | |||
| |||
| OCED Tractor Test 1631 | |
| Diesel Power shift 4WD September 1989 - October 1989, Link: OCED Tractor Test 1631 file | |
| PTO performance | |
| Max power | 276.95 hp 206.5 kW |
| Fuel use | 15.6 gal/hour 59.0 l/hour |
| Power at rated engine speed | 260.94 hp 194.6 kW |
| Fuel use | 15.9 gal/hour 60.2 l/hour |
| Power at rated PTO speed | 276.09 hp 205.9 kW |
| Fuel use | 16.2 gal/hour 61.3 l/hour |
| Drawbar performance | |
| Max power | 239.49 hp 178.6 kW |
| Fuel use | 16.4 gal/hour 62.1 l/hour |
| Gear 7 used for power test. | |
| Max pull | 32360 lbs 14678 kg |
| Gear 1 used for pull test. | |
