John Deere 2955
1987 - 1992 55 Utility Series Utility tractor
Series map:
2755
2955
3155
88.0hp
97.0hp
105.6hp*
*Estimated engine power for comparison only.
Production Manufacturer John Deere
Utility tractor Built in Mannheim, Baden-Württemberg, Germany Original price was $39,000 in 1992
John Deere 2955 Power Engine 97 hp72.3 kW
Drawbar (claimed) 74.2 hp55.3 kW
PTO (claimed) 85 hp63.4 kW
Drawbar (tested) 72.99 hp54.4 kW
PTO (tested) 86.22 hp64.3 kW
Performance test details ...
Mechanical Two- or four-wheel drive Power steering Differential hydraulic wet disc brakes Roll-Gard ROPS. Optional Sound-Gard cab.
Capacity Fuel 32 gal121.1 L
Hydraulic system 11.9 gal45.0 L
Hydraulics Type closed center
Capacity 11.9 gal45.0 L
Valves 1 to 3
Total flow 21 gpm79.5 lpm
Steering press. 2320 psi160.0 bar
Tractor hitch Rear Type II
Rear lift 5235 lbs2374 kg
Front Hitch II Opt Optional Front lift 3372 lbs1529 kg
Power Take-off (PTO) Rear PTO independent
Rear PTO Type 540/1000 (1.375)
Front PTO independent Opt Optional Front PTO Type 1000
2955 Serial Number Location Serial number plate on the right side of the tractor frame, above the front axle.
Electrical Ground negative
Charging system alternator
ROPS Charging amps 55
Cab Charging amps 85
Batteries 2
Battery CCA 600
Battery volts 12
Questions I'm looking at two different 148 loaders. One comes off a 4440, one comes off a 3020. I have a 2955. What kind of issues am I looking at with the mounts. Do either of these tractors have the same size as my 2955?
The 3020 and 4440 used the same mounts, but the mount would have been trimmed for the 3020. For your 2955 you need the utility tractor mounting brackets: AW20617 and AW20618.
Email: Peter@TractorData.com
References Powerful Pickups published in 1990, by John Deere Tractors 40 to 85 HP published in 1986, by John Deere Tractors 40 to 95 HP published in 1988, by John Deere Task Masters published in 1990, by John Deere 40 to 100 HP Tractors Product Information Handbook published in 1987, by John Deere 40 to 100 HP Tractors Product Information Handbook published in 1988, by John Deere 40 to 100 HP Tractors Product Information Handbook published in 1991, by John Deere The 1991 Long Green Line Agricultural Equipment Review published by John Deere
