John Deere 4050 Transmission

John Deere 4050 tractor photo
1983 - 1988
50 Series
Row-Crop tractor
Transmissions overview
16-speed partial power shift
15-speed full power shift
Transmission:John Deere Quad-Range
Type:partial power shift
Gears:16 forward and 6 reverse
Clutch:Perma-Clutch wet disc
Oil capacity:64 qts
60.6 L
Tractor must be stopped to select one of four ranges. Clutchless power shift between speeds 1-2 and 3-4 in range. A synchronized shift (using clutch) can be made between 2 and 3 in range.
With 18.4-38 rear tires
4050 Quad-Range partial power shift speeds
John Deere 4050 Quad-Range transmission photo
Transmission:John Deere Power Shift
Type:full power shift
Gears:15 forward and 4 reverse
Clutch:Perma-Clutch wet disc
Oil capacity:42 qts
39.7 L (2WD)
 54 qts
51.1 L (4WD)
Optional transmission. Full (clutchless) power shift can be made between gears, forward and reverse.
With 18.4-38 rear tires.
4050 Power Shift full power shift speeds
John Deere 4050 Power Shift transmission photo
