Tractors > John Deere > 3055

John Deere 3055



John Deere 3055 tractor photo
1992 - 1993
Utility tractor
Series map:
3055
3255
105.0hp
111.1hp*
*Estimated engine power for comparison only.
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $39,000 in 1993
John Deere 3055 Engine
John Deere 5.9L 6-cyl diesel
Engine details ...
John Deere 3055 Transmission
16-speed two-speed power shift
Transmission details ...
John Deere 3055 Power
Engine105 hp
78.3 kW
PTO (claimed)92 hp
68.6 kW
Drawbar (tested)76.6 hp
57.1 kW
PTO (tested)94.4 hp
70.4 kW
Performance test details ...
Mechanical
Two-wheel drive
Final drivesinboard planetary
Differential lockrear lock standard
Power steering
Hydraulic wet disc brakes
Four-post ROPS. Sound-Gard body and cab optional.
Photos
No photos of the John Deere 3055 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel32 gal
121.1 L
Hydraulic system13.2 gal
50.0 L
Hydraulics
Typeclosed center
Capacity13.2 gal
50.0 L
Valves1 to 3
Pump flow21 gpm
79.5 lpm
Tractor hitch
Rear TypeII
Controllower-link draft sensing
Rear lift (at 24"/610mm)5235 lbs
2374 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@2070
 1000@2170
Dimensions & Tires
Wheelbase100.4 inches
255 cm
Weight8457 to 9690 pounds
Front tire10.00-16
Rear tire18.4-34
Full dimensions and tires ...
3055 Serial Numbers
Location:Serial number plate on the right side of the tractor's frame, above the front axle.
1991717916
1992736426
1993768939

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Batteries2
Battery volts12
References
3055 references literature
Powerful Pickups published in 1990, by John Deere
40 to 100 HP Tractors Product Information Handbook published in 1991, by John Deere
