Tractors > John Deere > 830

John Deere 830 Tests



John Deere 830 tractor photo
1973 - 1975
Generation II Series
Utility tractor
Series map:
830
38.9hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 1146
830 fuel use from test 1146
Nebraska Tractor Test 1146
Diesel 8-speed 2WD
October 13 - 19, 1973
Link: Nebraska Tractor Test 1146 file
PTO performance
Power at rated engine speed35.30 hp
26.3 kW
Fuel use2.5 gal/hour
9.5 l/hour
Power at rated PTO speed32.62 hp
24.3 kW
Fuel use2.2 gal/hour
8.3 l/hour
Drawbar performance
Max power28.02 hp
20.9 kW
Fuel use2.4 gal/hour
9.1 l/hour
Gear 5 used for power test.
Max pull4,252 lbs
1928 kg
Gear 2 used for pull test.
