John Deere 2520 Transmission

John Deere 2520 tractor photo
1968 - 1972
Row-Crop tractor
Series map:
*Estimated engine power for comparison only.
Transmission options
8-speed full power shift
8-speed partially synchronized
TransmissionJohn Deere Powershift
Typefull power shift
Gears8 forward and 4 reverse
Clutchhydraulic wet discs
Oil capacity44 qts
41.6 L
2520 Powershift full power shift speeds
TransmissionJohn Deere Syncro-Range
Typepartially synchronized
Gears8 forward and 2 reverse
Clutchsingle dry disc
Oil capacity32 qts
30.3 L
Four shift stations with two forward gears each plus reverse gear in some stations. Shifts between gears within a station are synchronized. Tractor must be stopped to shift between stations.
2520 Syncro-Range partially synchronized speeds
