Massey Ferguson 860
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of Fermec) |
| Backhoe loader tractor | |
| Built in Manchester, England | |
| Massey Ferguson 860 Engine | |
| Perkins 4.0L 4-cyl diesel | |
| Fuel tank | 31.7 gal 120.0 L |
 Engine details ... | |
| Massey Ferguson 860 Transmission | |
| 4-speed power shuttle | |
 Transmission details ... |
| Massey Ferguson 860 Power | |
| Engine | 96 hp 71.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | outboard planetary |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS. Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 860 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 16.4 gpm 62.1 lpm |
| Total flow | 37.5 gpm 141.9 lpm |
| Steering flow | 21.1 gpm 79.9 lpm |
| Dimensions & Tires | |
| Wheelbase | 83.9 inches 213 cm |
| Weight | 16500 lbs 7484 kg |
| Front tire | 16/70-20 |
| Rear tire | 16.9-30 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 207.9 to 261 inches |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| MF Industrial 700/800/900 published in 1993, by Fermec | |
| Sales Manual Backhoe Loaders published by Fermec | |
| TLK860 Backhoe Loader published by Kobelco |
