J.I. Case 590 Turbo
|
|
| Production | |
| Manufacturer | J.I. Case |
| Backhoe loader tractor | |
| J.I. Case 590 Turbo Engine | |
| Case 3.9L 4-cyl diesel | |
 Engine details ... |
| J.I. Case 590 Turbo Transmission | |
| 4-speed power shuttle | |
 Transmission details ... |
| J.I. Case 590 Turbo Power | |
| Engine (gross) | 93 hp 69.4 kW |
| Engine (net) | 86 hp 64.1 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Four-post ROPS. Cab optional with air-conditioning. |
| Capacity | |
| Fuel | 33 gal 124.9 L |
| Hydraulic system | 34 gal 128.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 34 gal 128.7 L |
| Pressure | 2750 psi 189.6 bar |
| Pump flow | 31 gpm 117.3 lpm |
| 11 gpm 41.6 lpm | |
| Total flow | 42 gpm 159.0 lpm |
| Dimensions & Tires | |
| 2WD Wheelbase | 84 inches 213 cm |
| 4WD Wheelbase | 84.5 inches 214 cm |
| Weight | 13820 to 15765 pounds |
| Front tire | 11Lx16 |
| Rear tire | 19.5Lx24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 187.5 inches 476 cm |
| Dump angle | 45 inches 114 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 65 |
| 95 OptOptional | |
| Batteries | 1 |
| 2 OptOptional | |
| Battery CCA | 685 |
| Battery volts | 12 |
| References | |
 | |
| 590 turbo published in 1991, by J.I. Case | |
| 590 turbo published in 1993, by J.I. Case |
