J.I. Case 780D
|
|
| Production | |
| Manufacturer | J.I. Case |
| Backhoe loader tractor | |
| J.I. Case 780D Engine | |
| J.I. Case 5.9L 6-cyl diesel | |
 Engine details ... |
| J.I. Case 780D Transmission | |
| 3-speed power shift | |
 Transmission details ... |
| J.I. Case 780D Power | |
| Engine (gross) | 124 hp 92.5 kW |
| Engine (net) | 112 hp 83.5 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | outboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS canopy standard. Optional cab with available air-conditioning. | |
| Photos | |
 | |
 J.I. Case 780D photos... | |
| Capacity | |
| Fuel | 43 gal 162.8 L |
| Hydraulic system | 14.2 gal 53.7 L |
| Hydraulics | |
| Type | open center |
| Capacity | 14.2 gal 53.7 L |
| Pump flow | 31.5 gpm (main) 119.2 lpm |
| 27.8 gpm (aux) 105.2 lpm | |
| Steering flow | 27.8 gpm 105.2 lpm |
| Steering press. | 1750 psi 120.7 bar |
| Dimensions & Tires | |
| Wheelbase | 87 inches 220 cm |
| Weight | 23264 to 27424 pounds |
| Front tire | 14.00x17.5 |
| Rear tire | 21Lx24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 217 inches 551 cm |
| Dump angle | 52 inches 132 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 65 |
| Batteries | 2 |
| Battery CCA | 685 |
| Battery volts | 12 |
| References | |
 | |
| Model 780D Loader/Backhoe published in 1988, by J.I. Case |
