Ford 755B
|
|
| Production | |
| Manufacturer | Ford |
| Backhoe loader tractor | |
| Ford 755B Engine | |
| Ford 4.4L 4-cyl diesel | |
 Engine details ... |
| Ford 755B Transmission | |
| 3-speed power shift | |
 Transmission details ... |
| Ford 755B Power | |
| Engine (gross) | 104.8 hp 78.1 kW |
| Engine (net) | 100 hp 74.6 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Four-post FOPS. Cab optional with heater. | |
| Photos | |
| No photos of the Ford 755B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 39.5 gal 149.5 L |
| Hydraulic system | 20 gal (reservoir) 75.7 L |
| 43 gal (total system) 162.8 L | |
| Steering | 2 qts 1.9 L |
| Hydraulics | |
| Type | open center |
| Capacity | 20 gal (reservoir) 75.7 L |
| 43 gal (total system) 162.8 L | |
| Pressure | 2350 psi (loader) 162.0 bar |
| 2300 psi (backhoe) 158.6 bar | |
| Pump flow | 28 gpm (loader) 106.0 lpm |
| 44 gpm (backhoe) 166.5 lpm | |
| Steering flow | 5.6 gpm 21.2 lpm |
| Steering cap. | 2 qts 1.9 L |
| Dimensions & Tires | |
| Wheelbase | 89 inches 226 cm |
| Weight | 16920 to 17960 pounds |
| Front tire | 11.00-16 |
| Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 206 inches 523 cm |
| Dump angle | 50 inches 127 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 51 |
| Battery CCA | 750 |
| Battery volts | 12 |
| Battery AH | 128 |
| References | |
 | |
| 755B Specifications published in 1988, by Ford | |
| Construction Equipment Buyer's Guide published in 1989, by Ford |
