Ford 655D
| | 1993 - 1995 |
| D Series | | Backhoe loader tractor |
|
Series map:
575D
655D
675D
82.0hp
82.0hp
93.0hp
| Production |
| Manufacturer | Ford
|
| Backhoe loader tractor |
| Ford 655D Power |
| Engine (gross) | 82 hp
61.1 kW
|
| Engine (net) | 75 hp
55.9 kW
|
| Mechanical |
| Two- or four-wheel drive |
| Differential lock | rear standard
|
| Power steering |
| Wet disc brakes |
| Four-post ROPS/FOPS. Cab optional with air-conditioning. |
| Capacity |
| Fuel | 24 gal
90.8 L
|
| Hydraulic system | 21 gal*Total hydraulic system capacity. Reservoir capacity is 24.6L.
79.5 L
|
| Steering | 2.5 qts
2.4 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 21 gal*Total hydraulic system capacity. Reservoir capacity is 24.6L.
79.5 L
|
| Pressure | 2650 psi
182.7 bar
|
| Pump flow | 31 gpm
117.3 lpm
|
| Steering flow | 5.1 gpm
19.3 lpm
|
| Steering cap. | 2.5 qts
2.4 L
|
| Steering press. | 1950 psi
134.5 bar
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 55
|
| Battery CCA | 800
|
| Battery volts | 12
|
| References |
 |
| Ford Tractor Loader Backhoe 655D Specifications published in 1992 |
| Tractor Loader Backhoes 445D 555D 575D 655D 675D published in 1994, by Ford |
| Page information |
| Contact: Peter Easterlund |
| Updated on August 31, 2022 |
| Copyright 2022 TractorData LLC |
