J.I. Case 680E Construction King
|
|
| Production | |
| Manufacturer | J.I. Case |
| Backhoe loader tractor | |
| J.I. Case 680E Engine | |
| J.I. Case 5.5L 4-cyl diesel | |
 Engine details ... |
| J.I. Case 680E Transmission | |
| 4-speed power shuttle | |
 Transmission details ... |
| J.I. Case 680E Power | |
| Engine (gross) | 88 hp 65.6 kW |
| Engine (net) | 80 hp 59.7 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | outboard planetary |
| Photos | |
| No photos of the J.I. Case 680E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Hydraulic system | 35 gal 132.5 L |
| 36.5 gal (Extendahoe) 138.2 L | |
| Hydraulics | |
| Type | open center |
| Capacity | 35 gal 132.5 L |
| 36.5 gal (Extendahoe) 138.2 L | |
| Pump flow | 27.5 gpm 104.1 lpm |
| 18 gpm 68.1 lpm | |
| Total flow | 45.5 gpm 172.2 lpm |
| Dimensions & Tires | |
| Wheelbase | 84.25 inches 213 cm |
| Weight | 14700 to 16180 pounds |
| Front tire | 11.00x16 |
| Rear tire | 16.9x24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 192 inches 487 cm |
| Dump angle | 49 inches 124 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 35 |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| 1975 Spring Buyers Guide published by J.I. Case |
