Cub Cadet Sc2450
|
|
| Production | |
| Distributor | Cub Cadet |
| Manufacturer | Yanmar |
| Backhoe loader tractor | |
| Cub Cadet Sc2450 Engine | |
| Yanmar 0.9L 3-cyl diesel | |
| Fuel tank | 5.8 gal 22.0 L |
 Engine details ... | |
| Cub Cadet Sc2450 Power | |
| Engine (gross) | 24 hp 17.9 kW |
| PTO (claimed) | 16.5 hp 12.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Steering | hydraulic power |
| Wet disc brakes | |
| Photos | |
| No photos of the Cub Cadet Sc2450 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 3.5 gpm 13.2 lpm |
| 3.4 gpm (trans/PTO) 12.9 lpm | |
| Total flow | 6.9 gpm 26.1 lpm |
| Tractor hitch | |
| Rear Type | 1 (limited) |
| Control | position control |
| Rear lift (at 24"/610mm) | 661 lbs 299 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Engine RPM | 540@31111 |
| Mid PTO | independent |
| Mid PTO Type | 2100 |
| Engine RPM | 2100@3338 |
| Dimensions & Tires | |
| Wheelbase | 55.1 inches 139 cm |
| Weight | 2,525 lbs 1145 kg |
| Front tire | 18x8.5-10 |
| Rear tire | 26x12.0-12 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 76.5 inches 194 cm |
| Dump angle | 45 inches 114 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Sc2450 Multi-purpose Sub-compact Tractor published in 2011, by Cub Cadet | |
| Compact Tractors published in 2010, by Cub Cadet |
