Massey Ferguson 50C
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Backhoe loader tractor | |
| Variants | |
| 50C | industrial tractor |
| Massey Ferguson 50C Engine | |
| Perkins 3.9L 4-cyl diesel | |
 Engine details ... |
| Massey Ferguson 50C Transmissions | |
| 8-speed | |
| 6-speed manual shuttle | |
| 4-speed power shuttle with torque converter | |
 Transmission details ... |
| Massey Ferguson 50C Power | |
| Engine (gross) | 67.5 hp 50.3 kW |
| Engine (net) | 62 hp 46.2 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | outboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Differential mechanical wet disc brakes | |
| Four post ROPS canopy. Optional cab. | |
| Photos | |
| No photos of the Massey Ferguson 50C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 18 gal 68.1 L |
| Hydraulic system | 10 gal 37.9 L |
| Steering | 2 qts 1.9 L |
| Hydraulics | |
| Type | open center |
| Capacity | 10 gal 37.9 L |
| Pressure | 2000 psi 137.9 bar |
| Total flow | 26 gpm 98.4 lpm |
| Steering cap. | 2 qts 1.9 L |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| Dimensions & Tires | |
| Wheelbase | 84 inches 213 cm |
| Weight | 12400 lbs 5624 kg |
| Front tire | 11Lx16 |
| Rear tire | 16.9x24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 175 to 223 inches |
| Dump angle | 50 inches 127 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 37 |
| Battery volts | 12 |
| Battery AH | 180 |
| References | |
 | |
| Backhoe Loaders - Tractor Loaders - Industrial Tractors published in 1977, by Massey Ferguson | |
| Backhoe Loaders - Tractor Loaders - Industrial Tractors published in 1979, by Massey Ferguson | |
| Industrial Machinery Buyer's Guide published in 1980, by Massey Ferguson | |
| Backhoe Loaders - Tractor Loaders - Industrial Tractors published in 1981, by Massey Ferguson | |
| Industrial & Construction Machinery Sales Manual published in 1977, by Massey Ferguson* | |
| *Publication contains known errors. |
