Allis Chalmers 715C
| | 1982 - 1984 |
| 700C Series | | Backhoe loader tractor |
|
Series map:
714C
715C
65.0hp
65.0hp
| Production |
| Manufacturer | Allis Chalmers
|
| Backhoe loader tractor |
| Allis Chalmers 715C Power |
| Engine | 65 hp
48.5 kW
|
| Mechanical |
| Two-wheel drive |
| Final drives | inboard planetary
|
| Power steering |
| Mechanical wet disc brakes |
| Four-post ROPS/FOPS. |
| Capacity |
| Fuel | 20 gal
75.7 L
|
| Hydraulic system | 27 gal
102.2 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 27 gal
102.2 L
|
| Total flow | 29 gpm
109.8 lpm
|
| Steering flow | 5 gpm
18.9 lpm
|
| Steering press. | 1500 psi
103.4 bar
|
| 715C Serial Numbers |
| Location: | Serial number plate on the left side of the frame, just behind the engine bay.
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 42
|
| | 61 OptOptional
|
| Batteries | 1
|
| | 2 OptOptional
|
| Battery CCA | 95
|
| Battery volts | 12
|
| Battery Group | 30H
|
| References |
 |
| Operator's Manual 710C / 714C / 715C published in 1982, by Allis Chalmers |
