Caterpillar 416B
|
|
| Production | |
| Manufacturer | Caterpillar |
| Backhoe loader tractor | |
| Caterpillar 416B Engine | |
| Caterpillar 4.4L 4-cyl diesel | |
 Engine details ... |
| Caterpillar 416B Transmission | |
| 4-speed power shuttle | |
 Transmission details ... |
| Caterpillar 416B Power | |
| Engine (gross) | 77 hp 57.4 kW |
| Engine (net) | 74 hp 55.2 kW |
| Mechanical | |
| Drive | 4x2 2WD |
| 4X4 MFWD 4WD | |
| Final drives | inboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Four-post ROPS. Cab available with optional air-conditioning. | |
| Photos | |
| No photos of the Caterpillar 416B are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 28 gal 106.0 L |
| Hydraulic system | 20.7 gal 78.3 L |
| Hydraulics | |
| Type | closed center |
| Capacity | 20.7 gal 78.3 L |
| Pressure | 3000 psi 206.8 bar |
| Pump flow | 41 gpm 155.2 lpm |
| Dimensions & Tires | |
| 2WD Wheelbase | 83 inches 210 cm |
| 4WD Wheelbase | 81 inches 205 cm |
| Weight | 13700 to 14630 pounds |
| Front tire | 11L-16 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 174 inches 441 cm |
| Dump angle | 45 inches 114 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 52 |
| 90 OptOptional | |
| Battery CCA | 700 |
| Battery volts | 12 |
| References | |
 | |
| 416B Backhoe Loader published in 1992, by Caterpillar |
