John Deere 710B

John Deere 710B backhoe photo
1983 - 1988
Backhoe loader tractor
ManufacturerJohn Deere
TypeBackhoe loader tractor
John Deere 710B Engines
John Deere 5.4L 6-cyl diesel
John Deere 5.9L 6-cyl diesel
Engine details ...
John Deere 710B Power
Engine (gross)110 hp
82.0 kW
Engine (net)105 hp
78.3 kW
Chassis4x2 2WD
 4x4 MFWD 4WD
Final drivesinboard planetary
Brakeshydraulic wet disc
CabFour-post ROPS/FOPS. Cab available with air-conditioning.
No photos of the John Deere 710B are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Fuel33 gal
124.9 L
Hydraulic system20 gal
75.7 L
Typeclosed center
Capacity20 gal
75.7 L
Pressure2500 psi
172.4 bar
Pump flow53 gpm
200.6 lpm
Dimensions & Tires
2WD Wheelbase94 inches
238 cm
4WD Wheelbase96 inches
243 cm
Weight22500 lbs
10206 kg
Full dimensions and tires ...
Backhoe & Loader
Dig depth216 inches
548 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Charging systemalternator
Charging amps35
 51 (with cab)
 65 (with 359 engine)
710B reference literature
Utility Equipment Purchasing Guide published in 1987, by John Deere
Utility Equipment Purchasing Guide published in 1988, by John Deere
