John Deere Z860A


John Deere Z860A lawn tractor photo
2008 - 2009
Z-Trak PRO 800 Series
Zero-turn mower
Series:Z850AZ860A
Production
ManufacturerJohn Deere
TypeZero-turn mower
FactoryFuquay-Varina, North Carolina, USA
John Deere Z860A Engine
34HP Kawasaki 999cc 2-cyl gasoline
Fuel tank11.75 gal
44.5 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringpower
CabTwo-post folding ROPS.
Photos
No photos of the John Deere Z860A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelecto-magnetic
Dimensions & Tires
Wheelbase55 inches
139 cm
Weight1390 to 1469 pounds
Front tire13x6.5-6
Rear tire24x12-12
Full dimensions and tires ...
John Deere Z860A attachments
60" mid-mount mower deck
72" mid-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps15
Battery CCA300
Battery volts12
Battery GroupU1L
References
Z860A reference literature
Operator's Manual Z-Trak Pro Series (OMTCU26008) published in 2009, by John Deere
Z-Trak Professional Series (DKA2347) published in 2009, by John Deere
