Ariens RM1032
|
|
| Production | |
| Manufacturer | Ariens |
| Riding lawn mower | |
| Built in Brillion, Wisconsin, USA | |
| Variants | |
| 927007 | Tecumseh VM100 recoil |
| 927008 | Tecumseh VM100 electric |
| 927015 | Briggs 22 recoil |
| 927016 | Briggs 22 electric |
| 927023 | Briggs 22 electric |
| 927026 | Tecumseh TVM220 recoil |
| 927028 | Tecumseh TVM220 electric |
| Ariens RM1032 Engines | |
| 10HP Tecumseh 331cc 1-cyl gasoline | |
| 10HP Briggs & Stratton 360cc 1-cyl gasoline | |
| 10HP Tecumseh 357cc 1-cyl gasoline | |
| Fuel tank | 0.75 gal 2.8 L |
 Engine details ... | |
| Ariens RM1032 Transmission | |
| 6-speed fiction disc | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Manual steering | |
| Mechanical band brakes | |
| Open operator station. |
| Photos | |
| No photos of the Ariens RM1032 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | idler pulley |
| Dimensions & Tires | |
| Wheelbase | 45.5 inches 115 cm |
| Weight | 390 lbs 176 kg |
| Front tire | 4.10-3.50x4 |
| Rear tire | 16-6.50x8 |
 Full dimensions and tires ... | |
| Ariens RM1032 attachments | |
| 32" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| References | |
 | |
| Riding Mowers published in 1980, by Ariens |
