Honda HF2317


Honda HF2317 lawn tractor photo
2020 -
Lawn tractor
Series map:
HF2317
HF2417
11.3kw
11.3kw
Production
ManufacturerHonda
Lawn tractor
Honda HF2317 Engine
11.3KW Honda 529cc 2-cyl gasoline
Fuel tank1.4 gal
5.3 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Honda HF2317 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase45.3 inches
115 cm
Weight487 lbs
220 kg
Front tire13x5.00-6
Rear tire18x8.50-8
Full dimensions and tires ...
Electrical
Groundnegative
References
HF2317 references literature
HF2317 - HF2417 - HF2625 (CG71505502H16) published in 2019
Ride-on Mower and Lawn Tractors published in 2020, by Honda
