Lawn Tractors > Craftsman > 917.25157

Craftsman 917.25157

No photo available
1996
Garden tractor






Production:

Distributor:Craftsman (a part of Sears)
Manufacturer:AYP


Craftsman 917.25157 Engine:

   25HP Kohler 624cc 2-cyl gasoline
full engine details ...


Capacity:

Fuel:3.5 gal [13.2 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:electric


Dimensions & Tires:

full dimensions and tires ...


Craftsman 917.25157 attachments:

 50" mid-mount mower deck
all 917.25157 attachments ...


917.25157 Serial Numbers:


how to read serial numbers...



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.


Electrical:

Ground:negative
Charging amps:15


Battery:

Number:1
Cold-cranking amps:340
Volts:12
Amp-hours:40
Group:U1R
