John Deere X940

John Deere X940 lawn tractor photo
2018 -    X900 Series
Garden tractor
Series next:John Deere X948






Production:

Manufacturer:John Deere
Factory:Horicon, Wisconsin, USA


Variants:

X940:2WD 2-wheel steer
X948:4WD 2-wheel steer
X949:4WD 4-wheel steer


John Deere X940 Engine:

   24.5HP Yanmar 904cc 3-cyl diesel
full engine details ...


Capacity:

Fuel:5.2 gal [19.7 L]


Power Take-off (PTO):

Rear PTO:independent*Optional, linked with the mid PTO switch. Mechanical selector sets PTO to front, rear, or both.
Rear RPM:540
Mid PTO:independent
Clutch:electro-hydraulic
Mid RPM:2000


Dimensions & Tires:

Wheelbase:54.5 inches [138 cm]
Weight:1042 lbs [472 kg]
Front tire:18x8.50-8
Rear tire:26x12.00-12
full dimensions and tires ...


John Deere X940 attachments:

 48" mid-mount mower deck
 54" mid-mount mower deck
 60" mid-mount mower deck
all X940 attachments ...


X940 Serial Numbers:


how to read serial numbers...



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS.


Hydraulics:

Mid valves:2
Pump flow:5.7 gpm [21.6 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:40


Battery:

Number:1
Cold-cranking amps:340
Volts:12
