Lawn Tractors > John Deere > X106

John Deere X106



John Deere X106 lawn tractor photo
2018 - 2020
X100 Series
Lawn tractor
Series map:
X106
X126
7.6kw
10.7kw
Production
ManufacturerJohn Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
John Deere X106 Engine
7.6KW Briggs & Stratton 339cc 1-cyl gasoline
Fuel tank2.4 gal
9.1 L
Engine details ...
John Deere X106 Transmission
CVT
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the John Deere X106 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Wheelbase48.3 inches
122 cm
Weight412 lbs
186 kg
Front tire15x6.00-6
Rear tire20x8.0-8
Full dimensions and tires ...
John Deere X106 attachments
106 cm mid-mount mower deck
Attachment details ...
Electrical
Groundnegative
Charging amps9
Battery volts12
Battery GroupU1
References
X106 references literature
Lawn Care Solutions published in 2018, by John Deere
