Wheel Horse 418-C

Wheel Horse 418-C lawn tractor photo
1987 - 1987   400 Series
Garden tractor





The commercial 418-C was similar to the 418-A but offered an upgraded seat and front axle. It did not have the hood louvers or the chrome hub caps.


Production:

Manufacturer:Wheel Horse (a part of Toro)
Factory:South Bend, Indiana, USA


Variants:

418-8:gear
418-A:hydrostatic
418-C:commercial duty


Wheel Horse 418-C Engine:

   18HP Kohler 691cc 2-cyl gasoline
full engine details ...


Capacity:



Dimensions & Tires:

Wheelbase:45.5 inches [115 cm]
Weight:757 lbs [343 kg]
Front tire:16x6.50-8
Rear tire:23x10.50-12
full dimensions and tires ...


Wheel Horse 418-C attachments:

 60" mid-mount mower deck
all 418-C attachments ...


418-C Serial Numbers:

Location:Serial number plate on the left side of the Wheel Horse 418-A rear fender deck, below the seat. Model numbers shown.
photo of 418-C serial number

1987: 41-18KE01

how to read serial numbers...



Mechanical:

Transmission:hydrostatic
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station.


Electrical:

Ground:negative
Charging amps:15


Battery:

Number:1
Volts:12
