Lawn Tractors > Simplicity > Landlord 2012

Simplicity Landlord 2012

No photo available
1967 - 1967   Landlord Series
Garden tractor
Series back:Simplicity Landlord 2010






Production:

Manufacturer:Allis Chalmers
Factory:Port Washington, Wisconsin, USA


Variants:

990399:mechanical lift
990400:hydraulic lift


Simplicity Landlord 2012 Engine:

   12HP Briggs & Stratton 392cc 1-cyl gasoline
full engine details ...


Capacity:



Power Take-off (PTO):

Mid PTO:independent
Clutch:mechanical idler pulley


Dimensions & Tires:

Wheelbase:44.5 inches [113 cm]
Weight:690 lbs [312 kg]
Front tire:4.80-8
Rear tire:8.50-12
full dimensions and tires ...


Simplicity Landlord 2012 attachments:

 42" mid-mount mower deck
 snowblower
 blade
all Landlord 2012 attachments ...


Landlord 2012 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:3-speed gear
Transmission:6-speed
Chassis:4x2 2WD
Steering:manual
Brakes:mechanical band
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
