Cub Cadet 2146


Cub Cadet 2146 lawn tractor photo
2000 - 2001
2000 Series
Lawn tractor
Series map:
2146
2164
14.0hp
16.0hp
Production
ManufacturerCub Cadet (a part of MTD)
Lawn tractor
Cub Cadet 2146 Engine
14HP Linamar 388cc 1-cyl gasoline
Fuel tank2.25 gal
8.5 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase47 inches
119 cm
Weight710 lbs
322 kg
Front tire15x6.5
Rear tire20x9
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery CCA275
Battery volts12
Page information
Peter Easterlund - owner of TractorData.com
Copyright 2023 TractorData.com®
TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999.
Peter Easterlund - owner/author
Email: Peter@TractorData.com
Updated on November 8, 2016
https://www.cubcadet.com/en_US/operatorsmanuals - Official operator manuals for download from Cub Cadet.
