Toro Wheel Horse 522xi



Toro Wheel Horse 522xi tractor photo
1998 - 2006
5xi Series
Garden tractor
Series map:
520Lxi
522xi
523Dxi
20.0hp
22.0hp
23.0hp
Production
ManufacturerToro
Garden tractor
Original price was $7,619 in 1999
Toro 522xi Engine
22HP Kohler 674cc 2-cyl gasoline
Fuel tank4.25 gal
16.1 L
Engine details ...
Toro 522xi Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Power steering
Open operator station with adjustable seat.
Photos
Toro 522xi, left side.
Toro 522xi photos...
Power Take-off (PTO)
Front PTOindependent
Front PTO Typeelectric
Dimensions & Tires
Wheelbase52 inches
132 cm
Weight1022 lbs
463 kg
Front tire16x7.5
Rear tire23x10.50
Full dimensions and tires ...
Toro 522xi attachments
44" mid-mount mower deck
48" mid-mount mower deck
52" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
front-end loader
Attachment details ...
522xi Serial Number Location
Toro 522xi serial number location
Serial number decal on the rear fender of the 522xi, below the seat on the left.
Electrical
Groundnegative
Charging amps15
Battery CCA380
Battery volts12
References
Wheel Horse 522xi references literature
5xi Series Tractor Service Manual published in 1997
Lawn and Garden Tractors published in 1998, by Toro
Lawn and Garden Tractors published in 1999, by Toro
Lawn and Garden Tractors published in 2001, by Toro
