Cub Cadet 1105


No photo available
1985 - 1986
Lawn tractor
Series:80511051110
Production
ManufacturerCub Cadet (a part of MTD)
TypeLawn tractor
Variants
1105gear
1110hydrostatic
Cub Cadet 1105 Engine
Briggs & Stratton 399cc 1-cyl gasoline
Fuel tank3 gal
11.4 L
Engine details ...
Mechanical
Chassis4x2 2WD
Steeringmanual
CabOpen operator station.
Photos
No photos of the Cub Cadet 1105 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase45 inches
114 cm
Weight481 to 497 pounds
Front tire15x6-6
Rear tire20x10-8
Full dimensions and tires ...
Cub Cadet 1105 attachments
36" mid-mount mower deck
44" mid-mount mower deck
snowblower
blade
Attachment details ...
1105 Serial Numbers
Location:Left side of tractor frame.
Electrical
Groundnegative
Battery volts12
