John Deere D170



John Deere D170 lawn tractor photo
2011 - 2017
D100 Series
Lawn tractor
Series map:
D160
D170
25.0hp
25.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Greeneville, Tennessee, USA
Original price$2,799 (2011 )
$2,799 (2015 )
John Deere D170 Engine
25HP Briggs & Stratton 724cc 2-cyl gasoline
Fuel tank4 gal
15.1 L
 2.4 gal*California model
9.1 L
Engine details ...
John Deere D170 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical shoe on transaxle brakes
Open operator station. Adjustable 15-inch tall seat with 5.5-inches of travel in ten positions and lumbar adjustment. Fender-mounted cup holder. Optional nylon sunshade canopy or snow enclosure. Optional 12-volt power outlet.
Photos
John Deere D170
John Deere D170 photos...
Power Take-off (PTO)
Mid PTOelectric independent
Dimensions & Tires
Wheelbase48.9 inches
124 cm
Weight579 lbs
262 kg
Front tire16x6.5-8
Rear tire22x9.5-12
Full dimensions and tires ...
John Deere D170 attachments
54" mid-mount mower deck
snowblower
blade
Attachment details ...
D170 Serial Numbers
Location:Serial number on rear of tractor, left side, under fender.
Electrical
Groundnegative
Charging systemalternator
Charging amps16
Battery volts12
Battery GroupU1
References
D170 references literature
Riding Lawn Tractors published in 2015, by John Deere
Riding Lawn Tractors published in 2017, by John Deere
Riding Lawn Tractors published in 2016, by John Deere
D170 manuals literature
Operator's Manual D100 Series (OMGX24147) published in 2011
Operator's Manual D100 Series (OMGX24230) published in 2012
Operator's Manual D100 Series (OMGX24920) published in 2013
Operator's Manual D100 Series (OMGX25361) published in 2014
Operator's Manual D100 Series (OMGX25410) published in 2014
Operator's Manual D100 Series (OMGX25658) published in 2014
Operator's Manual D100 Series (OMGX26097) published in 2015
Operator's Manual D100 Series (OMUC11804) published in 2016
