Lawn Tractors > Ingersoll > 4018

Ingersoll 4018

Ingersoll 4018 lawn tractor photo
1989 - 1992   4000 Series
Garden tractor
Series next:Ingersoll 4020






Production:

Manufacturer:Ingersoll
Factory:Winneconne, Wisconsin, USA


Ingersoll 4018 Engine:

   18HP Onan 776cc 2-cyl gasoline
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:0


Dimensions & Tires:

Weight:960 lbs [435 kg]
Front tire:16x6.5-8
Rear tire:32x8-16
full dimensions and tires ...


Ingersoll 4018 attachments:

 44" mid-mount mower deck
 48" mid-mount mower deck
 60" mid-mount mower deck
all 4018 attachments ...


4018 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Chassis:4x2 2WD
Steering:manual gear and sector
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
