Lawn Tractors > Ingersoll > 4014

Ingersoll 4014



No photo available
1989 - 1990
4000 Series
Garden tractor
Series map:
4014
4016
14.0hp
16.0hp
Production
ManufacturerIngersoll
Garden tractor
Ingersoll 4014 Engine
14HP Kohler 512cc 1-cyl gasoline
Engine details ...
Ingersoll 4014 Transmission
hydraulic drive
Transmission details ...
Mechanical
Two-wheel drive
Manual steering
Mechanical band brakes
Open operator station.
Photos
No photos of the Ingersoll 4014 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel3 gal
11.4 L
Hydraulic system1.5 gal
5.7 L
Hydraulics
Typeopen center
Capacity1.5 gal
5.7 L
Pressure2000 psi (transmission)
137.9 bar
 575 psi (lift)
39.6 bar
Valves2
Pump flow8 gpm
30.3 lpm
Tractor hitch
Rear Type0 OptOptional
Typesleeve hitch OptOptional
Power Take-off (PTO)
Front PTOindependent
Clutchelectric
Front PTO Typepulley
Dimensions & Tires
Wheelbase48 inches
121 cm
Weight695 lbs
315 kg
Full dimensions and tires ...
Ingersoll 4014 attachments
44" mid-mount mower deck
48" mid-mount mower deck
60" mid-mount mower deck
snowblower
blade
Attachment details ...
4014 Serial Numbers
Location:Serial number plate on the left side of the tractor, above the footrest.
198914127550
199014127654

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Battery CCA230
Battery volts12
Battery AH32
References
4014 references literature
Compact Tractors 3010, 3012, 3014, 4014 (8-55970) published in 1989
