Honda H6522


Honda H6522 lawn tractor photo
1991 - 1996
Garden tractor
Production
ManufacturerHonda
TypeGarden tractor
Original price$12,149 (1995 )
Variants
H6522A22WD
H6522A44WD
Honda H6522 Engine
Honda 1235cc 3-cyl diesel
Engine details ...
Honda H6522 Transmission
9-speed three-speed power shift
Transmission details ...
Mechanical
Chassis4x2 2WD
 4x4 MFWD 4WD
Differential lockmechanical rear
Steeringpower assist
Brakesmechanical wet disc
CabTwo-post ROPS.
Capacity
Fuel4.5 gal
17.0 L
Hydraulic system3.4 gal
12.9 L
Hydraulics
Typeopen center
Capacity3.4 gal
12.9 L
Pressure2275 psi
156.9 bar
Pump flow3.96 gpm
15.0 lpm
Tractor hitch
Rear TypeI
Rear lift749 lbs
339 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540
Engine RPM540@2450
Mid PTOindependent
Mid RPM2000
Engine RPM2000@2485
Dimensions & Tires
Wheelbase62.6 inches
159 cm
Weight1645 to 1713 pounds
Front tire23x8.50-12
Rear tire33x12.50-15
Full dimensions and tires ...
Honda H6522 attachments
60" mid-mount mower deck
snowblower
blade
front-end loader
backhoe
Attachment details ...
Electrical
Charging systemalternator
Battery volts12
Battery AH47
References
H6522 reference literature
Honda Compact Diesel Tractor published in 1991
Owner's Manual Compact Tractor H6522 published in 1991, by Honda
