Honda H5518
| | 1991 - 1999 |
| Garden tractor |
|
Series map:
H5013
H5518
13.0hp
18.0hp
| Production |
| Manufacturer | Honda
|
| Garden tractor |
| Variants |
| H5518A2 | 2WD
|
| H5518A4 | 4WD
|
| Mechanical |
| Drive | 4x2 2WD (H5518A2)
|
| | 4x4 MFWD 4WD (H5518A4)
|
| Steering | manual four-wheel
|
| Mechanical shoe brakes |
| Two-post ROPS. |
| Capacity |
| Fuel | 2.5 gal
9.5 L
|
| Hydraulic system | 0.53 gal
2.0 L
|
| Hydraulics |
| Capacity | 0.53 gal
2.0 L
|
| Pressure | 1280 psi
88.3 bar
|
| Tractor hitch |
| Rear Type | 0
|
| Rear lift (at ends) | 550 lbs
249 kg
|
| Front lift | 550 lbs
249 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 2000
|
| Front PTO | independent
|
| Front RPM | 2650
|
| Electrical |
| Ground | negative
|
| Battery volts | 12
|
| Battery AH | 30
|
| References |
 |
| Honda Multi-Purpose Tractors published in 1994 |
