    Cub Cadet 102

    Cub Cadet 102 lawn tractor photo
    1965 - 1967   1X2/1X3 Series
    Garden tractor
    Previous model:Cub Cadet 100
    Next model:Cub Cadet 104
    Series next:Cub Cadet 122
    Series back:Cub Cadet 71






    Production:

    Manufacturer:International Harvester
    Factory:Louisville, Kentucky, USA


    Cub Cadet 102 Engine:

       10HP Kohler 391cc 1-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:1.625 gal [6.2 L]


    Power Take-off (PTO):

    Rear PTO:transmission
    Front PTO:independent
    Clutch:mechanical


    Dimensions & Tires:

    Wheelbase:43 inches [109 cm]
    Weight:780 lbs [353 kg]
    Front tire:4.80x4.00-8
    Rear tire:6-12
    full dimensions and tires ...


    Cub Cadet 102 attachments:

     38" mid-mount mower deck
     42" mid-mount mower deck
     48" mid-mount mower deck
     snowblower
     blade
    all 102 attachments ...


    102 Serial Numbers:

    Location:Serial number plate on the rear of the tractor.
    1965: 127161
    1966: 137051
    1967: 180268
    Final: 218009

    how to read serial numbers...



    Mechanical:

    Transmission:3-speed gear
    Transmission:6-speed
    Chassis:4x2 2WD
    Steering:manual
    Brakes:dry disc
    Cab:Open operator station.


    Electrical:

    Ground:negative
    Charging system:generator


    Battery:

    Number:1
    Volts:12
